• Isolated dual channel driver
• Input power supply voltage: 2.7V to 5.5V
• Driver-side power supply voltage: up to 28V with UVLOV
• Peak source and sink current 4A/6A
• High CMTI: ±100KV/μs
• Typical propagation delay: 19ns
• Maximum delay matching: 5ns
• Maximum pulse width distortion: 6ns
• Acceptable minimum input pulse width: 20ns
• operation temperature: -40℃~125℃
• Package type
SOIC14 wide-body
SOIC16 wide-body
• UL1577 certification:
SOW16: 5.7kVrms for 1 min.
SOW14: 5.7kVrms for 1 min.
• CQC certification: Meet GB4943.1-2011
• CSA certification: components conform to 5A
• VDE certification: DIN V VDE V 0884-11： 2017-1
• Isolated DC-DC and AC-DC power supplies for servers, telecommunications and industry
• DC-AC PV inverter
• Motor driver and EV charging
• UPS and battery charger
