• Supply voltage range: VCC-GND: 13V to 22V
• Source/sink drive current: 5A (peak)
• Rise time 9.2ns (typical), drop time 7.9ns (typical)
• Input to output propagation delay 75ns (maximum)
• UVLO undervoltage protection
• Desaturation (DESAT) protection
• FAULT reporting function
• NSD1015T supports bipolar power supply and NSD1015MT
supports Miller clamp
• Operating temperature range: -40°C~125°C
• SOP8 package
• Industrial servo driver, inverter
• HEV/EV compressor controller
• HEV/EV PTC
